Fully Automatic PP Intermittent Gluing Production Line(Third Generation)
PP Filter Cartridge Gluing: This production line can automatically apply adhesive to designated areas of PP filter cartridges (typically where the cartridge contacts the housing). This process is critical for ensuring the cartridge's sealing integrity and overall quality.
Intermittent Gluing: This refers to a production line that applies adhesive in a stop-and-go manner rather than continuously. This approach is typically employed in applications requiring precise adhesive control or to prevent adhesive waste. Intermittent gluing ensures accurate control during each application, avoiding excess or insufficient adhesive.
Order(MOQ) :
1Payment :
FOBProduct Origin :
Bengbu Anhui ChinaShipping Port :
Shanghai / Qingdao /Nanjing / YiwuLead Time :
15-30 Days
Product categoriesThe Fully Automatic PP Intermittent Gluing Production Line is primarily used for applying adhesive (bonding) to polypropylene (PP) filter elements or other material filter elements within the filter industry. This production line is designed to enhance production efficiency, improve product quality, and reduce labor costs, particularly in areas requiring precise adhesive application. It ensures uniform adhesive distribution and secure bonding.
Main Features
1. Adhesive application system comprises one 50kg hot melt adhesive machine and two sets of 26-point independent spray nozzle assemblies,
2. Equipped with 52 solenoid valves controllable via the main unit touchscreen,
3. Rotation speed, paper folding speed, conveyor belt speed, and adhesive application methods are all controlled via the computer touchscreen.
4. Glue gun spray performance: Continuous spraying, single-sided/double-sided application, surface glue cutoff, and folding after a specified amount of adhesive application.
5. The paper folding and wave-forming mechanism is adjustable vertically and horizontally, accommodating various filter cartridge specifications and heights.
6. Speed control: Automatically adjustable via computer. Servo control system synchronizes folding speed with conveyor belt speed, enabling precise control of adhesive-to-paper and paper-to-paper spacing.
Configuration List
1. Motor configuration: Servo motor, Brand: INOVANCE
2. Touchscreen configuration: 10-inch touchscreen, Brand: INOVANCE
3. PLC Programmable Controller: Brand: INOVANCE
Servo Drive: Brand: INOVANCE
4. Cylinders, Solenoid Valves, Pressure Regulators: Brand: Shanghai Shannais
Bearings: Brand: Harbin Bearing
5. General Electrical Components: Custom high-precision proximity switches, imported standard proximity switches, relays, and other small electrical components
6. Mechanical Components: Reinforced aluminum profile frame; shafts undergo electroplating treatment, others receive standard blackening treatment.
7. Process Flow: Feeding, gluing mechanism, nozzle closure, upper/lower fans, folding mechanism, transmission unit, synchronous belt, aluminum shaft conveyor.
8. Instrumentation Standard Components: All instruments installed rationally for easy disassembly.
Technical Specifications
| Item | Specification |
| Maximum product width |
700mm |
| Adjustable fold height range |
6–80mm (depending on material) |
| Production speed |
4–15m/min |
| Glue strip spacing |
25.4mm |
| Number of glue strips |
2×26 strips, each glue nozzle controlled by an electronic valve. Features automatic adhesive cutoff function. |
| Power supply voltage | 380V/50Hz |
| Total machine power | 15kW |
| Operating air pressure |
0.6MPa |
| Machine weight |
500kg |
| External dimensions |
1000×800×1500mm (L×W×H) |
Applications
This production line is ideal for gluing:
HVAC air filter material
Medium-efficiency & high-efficiency filter papers
Meltblown + nonwoven composite filter materials
Automotive air filter elements
Industrial dust filtration media
Purification equipment filter paper
Multi-layer pleated filter material
Suitable for factories in: air purification, cleanroom systems, automotive parts, household appliances, industrial filtration, and environmental protection industries.
Our Packing
Why Choose Us?
Professional Manufacturer with years of experience in filter machine production
Full-servo control system using INOVANCE high-precision components
Strong R&D capability supporting customization and special material requirements
High reliability with reinforced mechanical design & premium accessories
Comprehensive after-sales service including installation, training, and maintenance
Stable global supply with machines exported to multiple countries
Competitive pricing with factory direct sale advantage
